Series 20 Ball Bearing Lashing Orbit Block™
Single Sheave Lashing Block with Becket Hub
This Series 20 Orbit Block™ is a lightweight, high-performance single-sheave lashing block designed for efficient load handling in compact rigging systems.
Features:
- Integrated stainless steel hub for secure lashing attachment and through-sheave becket use
- Compatible with up to 4 mm (5/32") lashing
- Supplied with 750 mm (30") x 1.7 mm (1/16") lashing cord
- Smooth ball bearing sheave for reduced friction and improved efficiency
Specifications:
- Maximum rope diameter: 1/4"
- Maximum Working Load (MWL): 550 lb
- Breaking Load (BL): 1210 lb
- Sheave diameter: 3/4"
- Weight: 0.3 oz
Notes:
Block must be lashed through the hub. The supplied lashing line requires three passes through the head and hub to achieve rated load. MWL and BL are dependent on lashing strength; knots, splices, and stitching may reduce overall breaking load compared to the line itself. Certain soft shackles may have lower rated strength than the block system.
